The machine is used for the hot press formation of winding or stacking cells. The main functions include: automatic barcode scanning of incoming materials, automatic loading, hot pressing, Hi-pot test, extraction of NG products, etc. Hot pressing temperature, pressure, time, Hi-pot test parameters and results are linked with barcode information and are uploaded to MES system automatically.
Modular design and single module can be shielded separately once it fails;
Four-axis or six-axis robots are used for material loading and unloading,making it easy for maintenance;Precision of upper and lower heating plates:≤0.3mm,Cell consistency:99.99%;
The self-designed heating plate has the function of anti-tape diaphragm and tab via special treatment on the surface of heating plates;
Heating plate adopts special high temperature resistant heating piece,which has uniform temperature,good stabiity and long life time,also with over-temperature alarm system;
Highly compatible with multiple cell sizes and models,and can achieve quick changeover due to modular design of fixtures.
Production Capacity：12PPM、16PPM、24PPM、30PPM、40PPM、50PPM、100PPM（Customized According To Customer Demands）
First Pass Yield：≥99.9% Downtime Rate：≤1%
